Agriseeder™ Pro/Pro X Series

The Agriseeder direct drill enables farmers to establish crops with minimal soil disturbance compared to traditional inversion methods. It is an extremely efficient and cost-effective way to put crop in the ground, allowing the farmer to grow crops which can improve the soil and keep the land productive all year round.

The Agriseeder Pro Series is Erth Engineering’s flagship seed drill. The modular build chassis enables maximum flexibility allowing drills to be tailored to your specific requirements. Options include hoppers from 400L to 1000L, secondary hoppers to sow single products on the surface or down the slot in combination, front and rear harrows for slot and scratch seeding, multiple rollers, hydraulic markers, tramlines, muck screens, trailing kits and E Drive systems (folding series only), with 7′ touchscreen and built-in camera.

Benefits

Fertility retained at surface
Less moisture loss
Firm surface with minimal disturbance
Does not lift stones or drag trash
Delivers in hard and soft conditions
Exceptional performance wet and dry

Superb depth control on undulating ground
Faster and cheaper sward turnaround
Low hp requirement; tractors from 100hp
Slot created is a natural moisture trap
Slot created shelters the young seedling
Tilth created in slot

Crops

Single Product of In Combination

Models

Model	2.5m	3m 24 Row	3m 32 Row
HP	100hp	100+hp	120+hp
Row Width	104	125	94
Coulters	24	24	32
Weight	1650kg	1700kg	2050kg
Grass	Yes	Yes	Yes
Small Seeds	Yes	Yes	Yes
Cereals	Yes	Yes	No

Gallery

Agriseeder™ Pro/Pro X Series Options

Hoppers

Plastic Hopper: 400L Steel Hopper: 1000L

Secondary Hopper

Designed in house by Erth for precision delivery or small quantities. Stainless steel construction, can handle practically any compound (grass, microfert, pellets, peas). Smooth delivery with the ability to sow really low rates. Output can be either fed to the venturi in “down the slot” applications or broadcast on the surface.

For example:

Grass down the slot; clover on the surface.
Peas down the slot; clover on the surface.
Fodder crops down the slot; slug pellets on the surface.
Seed and fertilizer down the slot.

Hydraulic Front Harrow

Recommended to be used in burn off situations to reduce chemical suppression. Can also be used for slot and scratch seeding combinations or can help to improve visibility if drilling in hard to see conditions.

Rear Harrow

Toplink adjustable. Helps dust more fines into the slot and helps neutralise chemical suppression.

Alternative Rollers

E Drive

7″ touchscreen shows all functions. Built in camera.

Hydraulic Markers

Can be fitted at any time.

Trailing Kit

Chassis front to rear for strength. Mechanical transport locks and swivel drawbar for tighter turning.

Tramlines

Standard Kverneland dump to tank solenoid values and Kverneland control box.

Muckscreen

For working in damper conditions and paddocks that have just been grazed.

Agriseeder™ Brochure

Other Agriseeder™ Models

E-Series

A simplified set up with a 3m 24 row chassis and low level 170L plastic hooper.

MORE INFO

FOLDING

All the features of the Pro Series, 4m or 6m chassis with a 2.8m transport width.
